The ordering process for conduit spacers from Amur Trench is designed to be simple and efficient for contractors, engineers, and procurement teams across the United States. Each order follows a clear process that helps ensure accuracy, proper fit, and reliable delivery. Once your project details are reviewed and confirmed, your spacers move into production with minimal delays.
888-996-8288Every order begins with key project details such as conduit size, pipe type, spacing, hole count, and duct bank layout. These inputs form the base for accurate fabrication and proper system alignment.
Submit CAD drawings, sketches, or basic layouts. When full drawings are not available, measured configurations are sufficient to begin the review process. Our team evaluates all inputs to align them with production requirements.
Select from HDPE, PVC, or polypropylene based on installation conditions and project requirements. Each material option supports structural stability and consistent performance in field applications.
All specifications are checked against project requirements to confirm accuracy. If adjustments are needed, they are addressed before final approval. Once confirmed, the order is released for production.
After approval, manufacturing begins. Production typically takes 2 to 3 weeks depending on order size and complexity. Once completed, spacers are packaged and shipped directly to your project site anywhere in the United States.
For additional technical reference, review the product specifications below:
Covers conduit spacing, layout configurations, and duct bank installation requirements.
| Key Specifications for Duct Bank Conduit Spacers | |
|---|---|
| Density | 0.95–0.96 g/cc |
| Hardness | Shore D 65 |
| Tensile Strength | 3,000 psi |
| Elongation at Break | ≥500% |
| Impact Resistance | Izod Notched 3.0 ft-lb/in |
| Thermal Resistance | Heat deflection up to 165°F, Vicat softening point 268°F, Brittle below -103°F |
Includes bore spacing guidance, alignment structure, and installation considerations.
| Key Specifications for Bore Conduit Spacers | |
|---|---|
| Density | 0.95–0.96 g/cc |
| Hardness | Shore D 65 |
| Tensile Strength | 3,000 psi |
| Elongation at Break | ≥500% |
| Impact Resistance | Izod Notched 3.0 ft-lb/in, Tensile Impact 100 ft-lb/in² |
| Thermal Resistance | Heat deflection up to 165°F, Vicat softening point 268°F, brittle below -103°F |
| Melt Index | 0.35 g/min |
The ordering process does not require perfect drawings or fully finalized designs. Submissions are reviewed and clarified before production begins, making sure specifications are properly interpreted.
Our team aligns sizing, spacing, and material selection during the review stage so production proceeds with defined requirements and minimal correction cycles.
Amur Trench supplies conduit spacers built for consistent performance in underground installation projects for various commercial sectors nationwide. Every product is manufactured to meet jobsite requirements with dependable material quality.
If you need assistance with specifications, drawings, or material selection, the Amur Trench team is available to help. We support contractors and project teams with clear guidance and reliable production timelines.
Call or contact us today to get started with your order or request a quote. in Charlotte, Colorado Springs, Los Angeles, Denver, and other cities all over the US.
